I just ran into one of the weirdest errors I have seen in my Dynamics CRM/365 carreer, and I have seen a few.

The problem we had was that the case entity had stopped working more or less totally. When trying to open any type of case form either as a normal user or in the form editor, I got a more or less anonymous error message. After a lot of banging my head against the wall and loosing some of my few strands of hair, I finally with the help of Deepesh excellent blog article:
https://dynamicsofdynamicscrm.com/2015/09/22/error-resolutionthe-case-of-the-form-which-stopped-loading-in-dynamics-crm/
it got me on the right track. I did some URL-hacking to try to access the form editor directly and accidentaly got to a mixed form editor. Very weird, but it showed that the form itself wasn’t broken, hence there was something wrong further down… probably the fields, just as Deepesh’s error. And after removing all custom fields, I got it working. Then tediously going back and removing them one by one, I found the culprit, a custom Lookup to the Product.

To give you some more background:

When trying to edit any case form, I got the following error:

When trying to create a new case, I got the following error:

And if I downloaded the file, the contents was: (I have hightlighted the part which has some, but only slight relevance)

Unhandled Exception: System.ServiceModel.FaultException`1[[Microsoft.Xrm.Sdk.OrganizationServiceFault, Microsoft.Xrm.Sdk, Version=8.0.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35]]: System.Web.HttpUnhandledException: Microsoft Dynamics CRM has experienced an error. Reference number for administrators or support: #D856E3CEDetail:
<OrganizationServiceFault xmlns:i=”http://www.w3.org/2001/XMLSchema-instance” xmlns=”http://schemas.microsoft.com/xrm/2011/Contracts”>
  <ActivityId>a3831d4c-6557-4f8a-b558-ba8c01b97e21</ActivityId>
  <ErrorCode>-2147220970</ErrorCode>
  <ErrorDetails xmlns:d2p1=”http://schemas.datacontract.org/2004/07/System.Collections.Generic” />
  <Message>System.Web.HttpUnhandledException: Microsoft Dynamics CRM has experienced an error. Reference number for administrators or support: #D856E3CE</Message>
  <Timestamp>2017-06-29T13:12:03.5384906Z</Timestamp>
  <ExceptionRetriable>false</ExceptionRetriable>
  <ExceptionSource i:nil=”true” />
  <InnerFault>
    <ActivityId>a3831d4c-6557-4f8a-b558-ba8c01b97e21</ActivityId>
    <ErrorCode>-2147220970</ErrorCode>
    <ErrorDetails xmlns:d3p1=”http://schemas.datacontract.org/2004/07/System.Collections.Generic” />
    <Message>System.NullReferenceException: Microsoft Dynamics CRM has experienced an error. Reference number for administrators or support: #5CCC57F6</Message>
    <Timestamp>2017-06-29T13:12:03.5384906Z</Timestamp>
    <ExceptionRetriable>false</ExceptionRetriable>
    <ExceptionSource i:nil=”true” />
    <InnerFault i:nil=”true” />
    <OriginalException i:nil=”true” />
    <TraceText i:nil=”true” />
  </InnerFault>
  <OriginalException i:nil=”true” />
  <TraceText i:nil=”true” />
</OrganizationServiceFault>

Here are some facts:

  • We had installed a solution that is an upgraded solution, originally from CRM 4 via CRM 2011 and 2013. Not sure if the field definition from the earlier versions are causing this. Probably not.
  • I tried switching off all plugin steps. But it didn’t help at all. This is usually what Microsoft support will ask you to do when you have issues why I tried it myself. Always good to try and send this to Microsoft support when registering a support ticket.
  • I have tried spinning up a clean 8.2 Dyn 365 with no customizations, creating a solution with just the case entity and importing that. It did not work. Not very strange, as the problem was a field that is causing the problem. Adding solutions does not remove anything unless you are using managed solutions with patches etc.
  • I tried exporting a small solution with just the case forms and removed all custom fields from the customization file manually and reimported it. It did not work, which is not strange either, as the error was not on the form.
  • I tried creating cases via the API. That did work. I did not use the lookup field that I later found out was the culprit. Perhaps writing something to all fields in the case entity would have generated an error. The reason for doing this was that I wanted to see if I could get an exception in my code that contained more information than what I was getting in the UI. Hence I wasn’t at all happy that it did work.
  • I tried retrieving cases via the API. That did work. Again, not happy at all.
  • I tried to manufacture the URL to the form ( https://contoso.crm4.dynamics.com/main.aspx?appSolutionId=%7b<solutionguid>%7d&etc=<entityobjectid, 112 for case>&extraqs=formtype%3dmain%26formId%3d<Guid for the ofrm>%26action%3d-1&pagetype=formeditor) That did not work. No form URL with etc=112 works.
  • I tried to retrieve the form via the API, that works. Again, not happy, but at least it showed that there probably wasn’t any problem with the form.
  • I tried to manufacture a weird URL, with the correct form id with the incorrect EntityObjectID. That showed the form, but with the information that the form is for the “other” entity. Weird, but showed that there is actually nothing wrong with the form itself. I could even edit the caseform this way, move fields, remove fields, but not add new stuff. Totally unsupported way of editing a form, but when in love, war and when Dyn365 buggs out, anything is allowed.See below. This proved to be a very useful, as the form seemed for some very strange reason to be involved in this. The way I proved this was that I had an ”original”, instance where the error showed and one where I had got it to work, after removing some fields, and removing all unnecessary fields from the main form. After this I created a solution which only imported the form from the non-functioning instance for the case entity and imported it into the working instance. I had not expected the result, but it actually stopped working. With the error described above. So for some reason the form was part of the problem.
    A weird Form Editor – the Case form loaded with the Account Entity (EntityTypeCode=1). Be careful when using this, and use at your own risk!
  • I got the same error as above when I try to open the case form in the normal UI.
  • When I try to create a new case, I get the error shown in the file ”AnErrorHasOccuredWithTimeStampAndLog.png”
  • As for what happened with the system just before/during/when this error occurred, we were doing customizations on the case form from a spotty internet Connection, and the case for did work before.
  • In the field-section of the Case entity, I selected ”Custom” fields, and I have a notion that most of these errors are probably caused by code which mix up custom lookup fields with built in ones. So I would start by looking at lookup fields based on system entities with custom relationships to case like:
    • case 1:N case
    • product 1:N case
    • account 1:N case
    • contact 1:N case
    • pricelevel 1:N case
  • However you might have several fields that are causing errors (I did), and that might make it very tricky to find what is wrong. Cause once you managed to remove the last field causing the error, and then restore the solution and then remove it again, you will find that you are back to a non-functioning entity, and you will have to work your way through each of the fields, with all their dependencies again, until you find the next one. Hence the methodology becomes
    1. Export solution
    2. Remove fields until you get the entity to work. Document exactly which fields you try and in which order. Always work in the same order. Remove a field, try to open the case, remove the next field, try to open case form, and so on. All the time documenting, which fields and in which order.
    3. When you get the case form to work, import the solution again.
    4. Remove the the field(s) that you know are causing the problems.
    5. If, after this, it still does not work, go to 2.
  • After I removed the fields, and cleaned the form, I recreated the fields with the exact same schema-names and that worked perfectly. Not sure though how it will work when I export it, I am still not sure what is causing this. Probably some erroneous code in the case logic.
  • I was able to replicate this error on other instances. So the problem is certainly connected to the solution itself.


So to sum it up. This is most obviously a bug in the Dynamics 365 platform as it should never be able to go into this state. In my case entity the problem was two lookups AND the main ”Case” form. After removing the fields and removing all non-necessary stuff from the form by using a URL hack described above, I managed to get it working.

If you run into this, I hope you manage to fix it. It isn’t easy and it will take some time. Hopefully I have given you some pointers.

    Gustaf Westerlund
    MVP, Founder and CTO at CRM-konsulterna AB
